Viscosity baths AD

• Type: AD17
• Volume bath: 17 l
• Temperature: RT+10 ... 200 °C
• Temperature stability: ±0,01 °C
• Max. flow rate: 16.6
• Max. delivery pressure: 0.25 bar
• Type of display: LCD
• Heating capacity: 2200 W
• Bath depth: 279 mm
• Dim. ext. (Ø x H): 318 x 521 mm
• Power supply: 240 V·AC, 50 Hz
• Weight: 34 kg

Viscosity baths are suitable for precise temperature control tasks and have been specially designed for viscosity tests with all common capillary viscometers including ASTM D0445. 6 viscosimeter openings (Ø 51 mm) are located in the insulating and chemical-resistant DuraTop™ bath top. The devices are additionally equipped with a tap water cooling coil and an over-temperature protection.

• Round glass tank
• Advanced digital temperature controller
• 4 languages: english, french, spanish, german
• Swivel 180™ rotating controller
• Connectivity: Ethernet, USB A and B, RS232/ adressable RS485
• Variable speed pump with external circulation in open and closed loop
• Automatic performance optimization
• Single-point calibration capability
