Heating bath thermostats CC, with polycarbonate bath

Manufacturer: Peter Huber Kältemaschinenbau

per unit / excl. VAT€ 2,328.75 - € 2,632.50

Type

CC-106A
CC-108A
CC-110A
CC-112A
CC-118A

Volume bath

12 l
18 l
4.4 l
6 l
7.5 l

Weight

5 kg
6 kg
8 kg

Opening (WxD)

130 x 110 mm
130 x 210 mm
130 x 310 mm
275 x 161 mm
275 x 321 mm

Ext. dim. (WxDxH)

147 x 307 x 330 mm
147 x 407 x 330 mm
147 x 507 x 330 mm
333 x 360 x 335 mm
333 x 520 x 335 mm

Clear

Delivery and Shipping Article Overview

Heating bath thermostats CC, with polycarbonate bath

Item No. 4676

Manufacturer Item No.

Specifications

Material bath: PC
Temperature stability: ±0,02 K
Temperature: 25 ... 100 °C
Max. flow rate: 27
Max. suction capacity: 22 l/min
Max. delivery pressure: 0.7 bar
Max. suction pressure: 0.4 bar
Type of display: TFT
Operation: Touchscreen
Heating capacity: 2.1 kW
Power supply: 200 ... 240 V, 50/60 Hz
IP code: IP 20
Bath depth: 150 mm

Product Description

The transparent polycarbonate baths are suitable for temperatures up to 100 °C. All models come with a Pilot ONE immersion circulator mounted on a bath bridge. With a pump adapter, the combinations can be used for both externally closed and externally open (with optional level control) temperature applications. The devices are equipped with overtemperature and low level protection. The electronic upgrade function “E-grade” allows a simple and cost-effective functional expansion at any time.

Powerful pressure/suction pump

Large and full colour 5.7″ TFT Touchscreen

Simple menu navigation in 13 languages

Programmer with calendar/clock functions

Ethernet, RS232, and USB interface

Pt100 external sensor connection

2-point calibration for control sensors

Safety class III (FL) acc. to DIN 12876

Article Overview

Heating bath thermostats CC, with polycarbonate bath

SKU	Type	Volume bath	Weight	Opening (WxD)	Ext. dim. (WxDxH)	Name	Price	QuantitySelect all
9859203	CC-106A	4.4 l	5 kg	130 x 110 mm	147 x 307 x 330 mm	Heating bath thermostats CC, with polycarbonate bath - CC 106A, 4.4 l, 5 kg, 130 x 110 mm, 147 x 307 x 330 mm	per unit / excl. VAT€ 2,328.75	Heating bath thermostats CC, with polycarbonate bath quantity
9859204	CC-108A	6 l	6 kg	130 x 210 mm	147 x 407 x 330 mm	Heating bath thermostats CC, with polycarbonate bath - CC 108A, 6 l, 6 kg, 130 x 210 mm, 147 x 407 x 330 mm	per unit / excl. VAT€ 2,338.88	Heating bath thermostats CC, with polycarbonate bath quantity
9859205	CC-110A	7.5 l	6 kg	130 x 310 mm	147 x 507 x 330 mm	Heating bath thermostats CC, with polycarbonate bath - CC 110A, 7.5 l, 6 kg, 130 x 310 mm, 147 x 507 x 330 mm	per unit / excl. VAT€ 2,409.75	Heating bath thermostats CC, with polycarbonate bath quantity
9859206	CC-112A	12 l	8 kg	275 x 161 mm	333 x 360 x 335 mm	Heating bath thermostats CC, with polycarbonate bath - CC 112A, 12 l, 8 kg, 275 x 161 mm, 333 x 360 x 335 mm	per unit / excl. VAT€ 2,602.13	Heating bath thermostats CC, with polycarbonate bath quantity
9859207	CC-118A	18 l	8 kg	275 x 321 mm	333 x 520 x 335 mm	Heating bath thermostats CC, with polycarbonate bath - CC 118A, 18 l, 8 kg, 275 x 321 mm, 333 x 520 x 335 mm	per unit / excl. VAT€ 2,632.50	Heating bath thermostats CC, with polycarbonate bath quantity
