Dispersing heads for T 25 easy clean digital / T 25 easy clean control

Manufacturer: IKA-Werke GmbH & Co.KG

per unit / excl. VAT€ 1,615.00 - € 2,147.00

Type

S 25 EC-C-18 G
S 25 EC-C-18 G-ST
S 25 EC-C-25 F
S 25 EC-C-25 G
S 25 EC-C-25 G-ST
S 25 EC-T-C-18 G
S 25 EC-T-C-18 G-ST
S 25 EC-T-C-25 F
S 25 EC-T-C-25 G
S 25 EC-T-C-25 G-ST

Working volume

10 ... 1,500 ml
100 ... 2,000 ml
50 ... 2,000 ml

Stator Ø

18 mm
25 mm

Ø rotor

12.7 mm
13.4 mm
17 mm
18 mm
20 mm

Immersion depth

35 ... 150 mm
45 ... 150 mm

Final fineness suspension

10 ... 50 µm
15 ... 50 µm
5 ... 25 µm

Final fineness emulsion

1 ... 10 µm
1 ... 5 µm

Max. temperature

120 °C
180 °C

Clear

Delivery and Shipping Article Overview

Dispersing heads for T 25 easy clean digital / T 25 easy clean control

Item No. 5587

Manufacturer Item No.

Specifications

Material: Stainless steel/Ceramic

Product Description

Easy to clean dispersing head made of stainless steel (AISI 316) and ceramic. Ultimate fineness: emulsions 1µm to 10 µm and suspensions 10 µm to 50 µm, sterilisable by all methods.

S 25 EC-T-C-25G-ST, S 25 EC-T-C-25F with integrated temperature sensor.

Article Overview

Dispersing heads for T 25 easy clean digital / T 25 easy clean control

SKU	Type	Working volume	Stator Ø	Ø rotor	Immersion depth	Final fineness suspension	Final fineness emulsion	Max. temperature	Name	Price	QuantitySelect all
4684822	S 25 EC-C-18 G	10 ... 1,500 ml	18 mm	12.7 mm	35 ... 150 mm	10 ... 50 µm	1 ... 10 µm	180 °C	Dispersing heads for T 25 easy clean digital / T 25 easy clean control - S 25 EC C 18 G, 10 ... 1,500 ml, 18 mm, 12.7 mm, 35 ... 150 mm, 10 ... 50 µm, 1 ... 10 µm, 180 °C	per unit / excl. VAT€ 1,615.00	Dispersing heads for T 25 easy clean digital / T 25 easy clean control quantity
4684824	S 25 EC-T-C-18 G	10 ... 1,500 ml	18 mm	12.7 mm	45 ... 150 mm	10 ... 50 µm	1 ... 10 µm	120 °C	Dispersing heads for T 25 easy clean digital / T 25 easy clean control - S 25 EC T C 18 G, 10 ... 1,500 ml, 18 mm, 12.7 mm, 45 ... 150 mm, 10 ... 50 µm, 1 ... 10 µm, 120 °C	per unit / excl. VAT€ 1,900.00	Dispersing heads for T 25 easy clean digital / T 25 easy clean control quantity
6291623	S 25 EC-C-18 G-ST	10 ... 1,500 ml	18 mm	13.4 mm	35 ... 150 mm	10 ... 50 µm	1 ... 10 µm	180 °C	Dispersing heads for T 25 easy clean digital / T 25 easy clean control - S 25 EC C 18 G ST, 10 ... 1,500 ml, 18 mm, 13.4 mm, 35 ... 150 mm, 10 ... 50 µm, 1 ... 10 µm, 180 °C	per unit / excl. VAT€ 1,718.00	Dispersing heads for T 25 easy clean digital / T 25 easy clean control quantity
4684826	S 25 EC-T-C-18 G-ST	10 ... 1,500 ml	18 mm	13.4 mm	45 ... 150 mm	10 ... 50 µm	1 ... 10 µm	120 °C	Dispersing heads for T 25 easy clean digital / T 25 easy clean control - S 25 EC T C 18 G ST, 10 ... 1,500 ml, 18 mm, 13.4 mm, 45 ... 150 mm, 10 ... 50 µm, 1 ... 10 µm, 120 °C	per unit / excl. VAT€ 2,002.00	Dispersing heads for T 25 easy clean digital / T 25 easy clean control quantity
4684823	S 25 EC-C-25 G	50 ... 2,000 ml	25 mm	17 mm	35 ... 150 mm	15 ... 50 µm	1 ... 10 µm	180 °C	Dispersing heads for T 25 easy clean digital / T 25 easy clean control - S 25 EC C 25 G, 50 ... 2,000 ml, 25 mm, 17 mm, 35 ... 150 mm, 15 ... 50 µm, 1 ... 10 µm, 180 °C	per unit / excl. VAT€ 1,686.00	Dispersing heads for T 25 easy clean digital / T 25 easy clean control quantity
4684825	S 25 EC-T-C-25 G	50 ... 2,000 ml	25 mm	17 mm	45 ... 150 mm	15 ... 50 µm	1 ... 10 µm	120 °C	Dispersing heads for T 25 easy clean digital / T 25 easy clean control - S 25 EC T C 25 G, 50 ... 2,000 ml, 25 mm, 17 mm, 45 ... 150 mm, 15 ... 50 µm, 1 ... 10 µm, 120 °C	per unit / excl. VAT€ 1,971.00	Dispersing heads for T 25 easy clean digital / T 25 easy clean control quantity
4672774	S 25 EC-C-25 G-ST	50 ... 2,000 ml	25 mm	20 mm	35 ... 150 mm	15 ... 50 µm	1 ... 10 µm	180 °C	Dispersing heads for T 25 easy clean digital / T 25 easy clean control - S 25 EC C 25 G ST, 50 ... 2,000 ml, 25 mm, 20 mm, 35 ... 150 mm, 15 ... 50 µm, 1 ... 10 µm, 180 °C	per unit / excl. VAT€ 1,789.00	Dispersing heads for T 25 easy clean digital / T 25 easy clean control quantity
4672776	S 25 EC-T-C-25 G-ST	50 ... 2,000 ml	25 mm	20 mm	45 ... 150 mm	15 ... 50 µm	1 ... 10 µm	120 °C	Dispersing heads for T 25 easy clean digital / T 25 easy clean control - S 25 EC T C 25 G ST, 50 ... 2,000 ml, 25 mm, 20 mm, 45 ... 150 mm, 15 ... 50 µm, 1 ... 10 µm, 120 °C	per unit / excl. VAT€ 2,074.00	Dispersing heads for T 25 easy clean digital / T 25 easy clean control quantity
4672775	S 25 EC-C-25 F	100 ... 2,000 ml	25 mm	18 mm	35 ... 150 mm	5 ... 25 µm	1 ... 5 µm	180 °C	Dispersing heads for T 25 easy clean digital / T 25 easy clean control - S 25 EC C 25 F, 100 ... 2,000 ml, 25 mm, 18 mm, 35 ... 150 mm, 5 ... 25 µm, 1 ... 5 µm, 180 °C	per unit / excl. VAT€ 1,859.00	Dispersing heads for T 25 easy clean digital / T 25 easy clean control quantity
4672777	S 25 EC-T-C-25 F	100 ... 2,000 ml	25 mm	18 mm	45 ... 150 mm	5 ... 25 µm	1 ... 5 µm	120 °C	Dispersing heads for T 25 easy clean digital / T 25 easy clean control - S 25 EC T C 25 F, 100 ... 2,000 ml, 25 mm, 18 mm, 45 ... 150 mm, 5 ... 25 µm, 1 ... 5 µm, 120 °C	per unit / excl. VAT€ 2,147.00	Dispersing heads for T 25 easy clean digital / T 25 easy clean control quantity
